IBM ThinkPad T23
The IBM ThinkPad T23 features the Intel Pentium III 1130MHz processor with 133MHz Front Bus Speed and 4X AGP Support, 256MB of 133MHz memory expandable to 1024MB and a Fast 30GB hard drive. Watch your favorite movies on the big screen with the S-Video Out port and the removable CDRW drive. The IBM ThinkPad T23 also utilizes the S3 Super Savage video with the 14.1-inch XGA LCD and massive 16MB SGRAM Video memory for clear, crisp and beautiful graphics. The IBM ThinkPad T23 gives you a complete Internet communications solution with the integrated 56k modem and broadband-ready 10/100Mbps NIC, and the Microsoft Windows 2000 Professional operating system. The ThinkPad T23 is a complete and affordable portable solution!
The ThinkPad T23 features:
-
Intel(R) Mobile Pentium(R) III processor at 1130 MHz featuring Intel(R) SpeedStep(TM) technology for both maximum and battery-optimized performance
-
Sleek profile and light weight
-
Microsoft (R) Windows (R) 2000 Professional
-
Easy one-button access to information on your system via portals to the Web with the new ThinkPad button
-
133 MHz front-side system bus with 133 MHz memory modules
-
256 MB of memory is standard (512mb Upgrade Available for $69)
-
30.0GB EIDE hard disk drive (HDD)
-
Integrated Mini-PCI V.90 modem(3) or Intel or 3Com combination V.90 56Kb modem and 10/100 Ethernet LAN connection
-
Brilliant display 358.1-mm (14.1-in) TFT display with 1024 x 768 resolution
-
Enhanced graphics enabling multiple monitor(4) support
-
DVD drive (CDRW/DVD option Available for $79)
-
Many optional features to enhance flexibility and function
-
Advanced system manageability
-
S-Video out port (TV out)
|
|
Slim Design
The IBM ThinkPad T23 is 33.1 mm (1.3 in) thin with optimal travel configurations weighing 2.1 kg (4.6 lb). Its dimensions are 304 x 250 mm (20.0 x 9.8 in). The new titanium composite cover gives you added strength(11).
|
|
|
Front Side View
|
1. UltraPort Connector :
All ThinkPad T23 models come with an UltraPort connector on the edge of the top panel. This innovative port supports an optional digital camera and power-management functions required by Bluetooth(TM) wireless options. The location of the port allows optimal performance for both applications.
2. Display panel :.XGA 1024X768 Resolution
3. LED Status display .
4. Volume Control : .
5. ThinkPad Buttons :
one-button access to information you need, along with ThinkPad portals for mobile solutions, service, support, and more.
6. TrackPoint IV :
7. Mouse & Scroll Button :
Press-to-Select and Release-to-Select features allow tapping of the TrackPoint pointing device to speed icon launches and reduce keystrokes.
8. UltraBay 2000 : |
| |
Right Side View
|
1. UltraBay 2000
With the Ultrabay 2000, fast and easy hot- and warm-swapping of many components gives you the flexibility to configure the system. |
| |
Left Side View
|
1. Cooler
2. 2PC Card slots :
3. Infrared
4. Headphone jack :
5. Line in
6. Microphone jack : |
| |
Rear Side View
|
1. Security Lock slot :
2. S-Video out
3. Serial port
4. Parallel port :
5. External Display port :
6. RJ-11 Modem port :
7. RJ-45 LAN port :
8. AC jack :
9. USB port :
10. PS/2 port : |
|
Latest processor technology
Operating system
Communications
Multimedia
DVD movie playback does not require complementary graphics hardware on ThinkPad T23 systems that have a DVD drive and
Windows 2000 installed.
LCD TFT display
Video Modes -- T23 (16MB SGRAM)
Laptop internal screen resolution 1024X768
External resolution 166x1200
Colors 16,000,000
Keyboard and TrackPoint with enhanced features
The keyboard has the familiar layout of a ThinkPad system with function keys that allow you to quickly access system functions such as power-management control.
The TrackPoint with enhanced features incorporates the Press-to-Select and Release-to-Select function.
Just tap the TrackPoint to speed icon launches and help reduce keystrokes. The new programmable center button enables fast scrolling of Web sites and documents or fast panning across wide spreadsheets. Switch to the innovative magnifying glass feature to enlarge screen views in any application.
Memory
The system has 256 MB of 133MHz memory standard and can be configured for up to 1024 MB of addressable memory.
PC Card
The Type III slot accommodates either two Type I, | two Type II, or one Type III PC card. The slot supports CardBus adapters, PC card, and Zoomed Video (ZV) adapter.
Storage
the customer-removable HDD 30.0 standard.
Drives
a DVD drive is installed in the system. (CDRW/DVD option Available for $79)
An optional SuperDisk (LS120) drive, or a second HDD in the Ultrabay 2000, expands storage. The second HDD option, requiring an adapter, can be used with all ThinkPad T23 models. The 1.44 MB diskette drive (FDD) can be plugged directly into the ThinkPad T23 Ultrabay 2000 or attached externally for added flexibility by using an optional adapter and cable available at ordering
Audio
Full-duplex audio on the system board and the integrated microphone allow voice annotation and audio. The system is equipped with audio in/out jacks for stereo speakers, headphone, or external microphone. The system supports Sound Blaster audio applications.
Video
Models with Windows 98 Second Edition support a system display and an external monitor simultaneously while different applications are on each screen. Move the cursor from one screen to the other and drag and drop items from the application on one screen to the application on the second screen.
Infrared
The system has one fast IR transceiver (up to 4 Mbps) for wireless file and data transfer and printing. The ThinkPad T23 is designed for compliance with the Infrared Data Association (IrDA) IR data link specification Version 1.1.
Other features
The ThinkPad T23 systems include these ports:
The USB port, which connects external drives and other devices, is supported by Microsoft Windows 2000 Professional, Windows 98, Windows 98 Second Edition, or Windows 95 OSR2.1, or later. Video out port (TV out) is standard.
The 240-pin connector supports these optional docking solutions:
